Warm White LED Tape | LED Strip from Scenex Lighting by GLP

The Warm White LED Tape from Scenex Lighting is IP65 rated, and and can be trimmed to any custom size as required, providing a versatile lighting platform for indoor and outdoor lighting designs.

Scenex also offer a range of different power supply and DMX drive options, including Artnet integration for larger systems.

We are happy to consult and advise on any system design. Free of charge and without obligation, in order to help support and make your vision become a reality.

Contact us for more information on the Warm White LED Tape
Want to stay up to date with the latest from Scenex?
Click the link here to sign up for Scenex’s mailing lists

Part Number	50503WW-60	50503WW	50505WW
Color	Warm white	Warm white	Warm white
Wavelength	n/a	n/a	n/a
Color temp	2800K-3200K	2800K-3200K	2800K-3200K
Lumens pr. mtr. / pr strip	720 / 2160	360 / 1080	360 / 1800
LED’s pr mtr / pr strip	60 / 180	30 / 90	30 / 150
LED type	SMD 5050	SMD 5050	SMD 5050
Field angle	120°	120°	120°
Housing material	Flexible strip with silicone covering	Flexible strip with silicone covering	Flexible strip with silicone covering
Color	White	White	White
Protection rating	IP 65	IP 65	IP 65
Mounting	Adhesive backing	Adhesive backing	Adhesive backing
Wiring connection	2 cable tail (V-, V+)	2 cable tail (V-, V+)	2 cable tail (V-, V+)
Power voltage	12V	12V	12V
Current pr mtr. / pr strip	14.4W / 43.2W	7.2W / 21.6W	7.2W / 36W
Energy saving class	Class A	Class A	Class A
Operating temp.	5°F – 104°F (-15°C – 40°C)	23°F – 104°F (-5°C – 40°C)	23°F – 104°F (-5°C – 40°C)
Cutting possibility	Every 1.9″ (5 cm)	Every 3.9″ (10 cm)	Every 3.9″ (10 cm)
Dimensions – inches	L x W x H 118.1″ x 0.4″ x 0.1″	L x W x H 118.1″ x 0.5″ x 0.1″	L x W x H 196.8″ x 0.47″ x 0.1″
Dimensions – centimetres	L x W x H 300 cm x 1.0 cm x 0.3 cm	L x W x H 300 cm x 1.2 cm x 0.3 cm	L x W x H 500 cm x 1.2 cm x 0.3 cm

Data Sheet

Scenex Lighting LED Tape

Scenex Lighting LED Tape Riser Diagram
